Toyota FJ Cruiser
Engine
The FJ Cruiser uses the 4.0L 1GR-FE DOHC V6 with VVT-i, rated at 239 hp at 5200 rpm, and 278 lb·ft of torque at 2700 rpm. It is the same engine that is used in some versions of the Tacoma and 4Runner. For the 2010 model year the FJ Cruiser's engine gains Dual VVT-i resulting in an additional 19 hp and improved fuel economy.
Drivetrains
5-speed A750E automatic transmission (on rear-wheel drive models)+ a triple rear track on the front wheels. 5-speed A750F automatic transmission with VF2A transfer case (made in Japan) (on Part-time 4x4 models) 6-speed RA61F manual transmission with VF4B transfer case and limited slip differential (on Full-time 4x4 models)
4WD System
4WD models equipped with the RA61F manual transmission have a full time 4WD system that is permanently engaged for use on all surfaces, both on and off road. Automatic transmission 4WD models have a simpler part time system which can only operate in 4WD mode on slippery surfaces without binding and possible damage to the 4WD system.
Suspension
The FJ Cruiser uses a high-mounted, double wishbone front suspension and stabilizer bar, and a 4-link rear suspension with lateral rod with coil springs and stabilizer bar. The 120-series Land Cruiser Prado shares the same suspension parts as the FJ Cruiser.
Brakes
The FJ Cruiser uses power-assisted 4-piston front/2-piston rear ventilated disc brakes with Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist (BA) and is also equipped with Vehicle Stability Control (VSC) with Traction Control (TRAC).
Body
The FJ's body features rear access doors that give a unique look to the SUV. The FJ captures its heritage with its short wheel base, stocky frame, and grille/headlight arrangement. The windshield is nearly vertical with three windshield wipers for maximum surface area coverage. Structurally, it is a "body on frame" truck style design based on the Hilux platform. Toyota has made revisions to the engine bay inner fender aprons due to some bulging and cracking issues with 2007 and some early 2008 models. The bulges and cracks in the inner fenders were attributed to a Toyota design flaw through certain VIN numbers. Toyota has addressed the problem and has changed the design to specs.
Features
The 2007 FJ Cruiser was available in 5 colors - "Sun Fusion" (yellow), "Black Cherry" (dark magenta), "Titanium Metallic" (silver), "Black Diamond" (black), and "Voodoo Blue" (blue). Available options and packages include:
Convenience Package - tri-wiper configuration; a remote keyless entry system; cruise control; power outside mirrors with illuminated markers; rear privacy glass; rear wiper; rear intuitive parking assist; and daytime running lights.
Upgrade Package 1 - 17-in., 6-spoke aluminum alloy wheels with P265/70R17 tires with exterior rear-door mounted full-size spare; Active Traction Control (4WD only); electronically locking rear differential; 115V, 400w power outlet; AM/FM 6-disc in-dash CD changer, MP3/WMA playback capability, and 8 speakers; exterior color-keyed door trim inserts; multi-information display floating ball type (with inclinometer, compass, and temperature); leather-wrapped steering wheel with integrated audio controls; and aluminum brush transmission lever and transfer lever (on 4WD models).
Upgrade Package 2 - similar to Upgrade Package 1, except the stereo includes a subwoofer with off switch. Other options include driver and front passenger front-seat mounted side airbags and front- and second-row side curtain airbags.There are a number of accessories available to the FJ Cruiser, including such things as running boards, rock rails, roof rack, front skid plate, brush guard, Garmin portable navigation device, spare tire cover, passenger-side armrest, dash applique, tow hitch, cargo mats, and cargo net.
Safety
Side curtain airbags for both rows and side torso airbags optional on 2007 models became standard on 2008 models, Vehicle Stability Control is standard.
The IIHS has awarded the FJ Cruiser its Top Safety Pick accolade. The FJ Cruiser received a "Good" overall rating in both the front and side impacts tests and also received the "Good" rating in all 14 measured categories.
The FJ Cruiser uses the 4.0L 1GR-FE DOHC V6 with VVT-i, rated at 239 hp at 5200 rpm, and 278 lb·ft of torque at 2700 rpm. It is the same engine that is used in some versions of the Tacoma and 4Runner. For the 2010 model year the FJ Cruiser's engine gains Dual VVT-i resulting in an additional 19 hp and improved fuel economy.
Drivetrains
5-speed A750E automatic transmission (on rear-wheel drive models)+ a triple rear track on the front wheels. 5-speed A750F automatic transmission with VF2A transfer case (made in Japan) (on Part-time 4x4 models) 6-speed RA61F manual transmission with VF4B transfer case and limited slip differential (on Full-time 4x4 models)
4WD System
4WD models equipped with the RA61F manual transmission have a full time 4WD system that is permanently engaged for use on all surfaces, both on and off road. Automatic transmission 4WD models have a simpler part time system which can only operate in 4WD mode on slippery surfaces without binding and possible damage to the 4WD system.
Suspension
The FJ Cruiser uses a high-mounted, double wishbone front suspension and stabilizer bar, and a 4-link rear suspension with lateral rod with coil springs and stabilizer bar. The 120-series Land Cruiser Prado shares the same suspension parts as the FJ Cruiser.
Brakes
The FJ Cruiser uses power-assisted 4-piston front/2-piston rear ventilated disc brakes with Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist (BA) and is also equipped with Vehicle Stability Control (VSC) with Traction Control (TRAC).
Body
The FJ's body features rear access doors that give a unique look to the SUV. The FJ captures its heritage with its short wheel base, stocky frame, and grille/headlight arrangement. The windshield is nearly vertical with three windshield wipers for maximum surface area coverage. Structurally, it is a "body on frame" truck style design based on the Hilux platform. Toyota has made revisions to the engine bay inner fender aprons due to some bulging and cracking issues with 2007 and some early 2008 models. The bulges and cracks in the inner fenders were attributed to a Toyota design flaw through certain VIN numbers. Toyota has addressed the problem and has changed the design to specs.
Features
The 2007 FJ Cruiser was available in 5 colors - "Sun Fusion" (yellow), "Black Cherry" (dark magenta), "Titanium Metallic" (silver), "Black Diamond" (black), and "Voodoo Blue" (blue). Available options and packages include:
Convenience Package - tri-wiper configuration; a remote keyless entry system; cruise control; power outside mirrors with illuminated markers; rear privacy glass; rear wiper; rear intuitive parking assist; and daytime running lights.
Upgrade Package 1 - 17-in., 6-spoke aluminum alloy wheels with P265/70R17 tires with exterior rear-door mounted full-size spare; Active Traction Control (4WD only); electronically locking rear differential; 115V, 400w power outlet; AM/FM 6-disc in-dash CD changer, MP3/WMA playback capability, and 8 speakers; exterior color-keyed door trim inserts; multi-information display floating ball type (with inclinometer, compass, and temperature); leather-wrapped steering wheel with integrated audio controls; and aluminum brush transmission lever and transfer lever (on 4WD models).
Upgrade Package 2 - similar to Upgrade Package 1, except the stereo includes a subwoofer with off switch. Other options include driver and front passenger front-seat mounted side airbags and front- and second-row side curtain airbags.There are a number of accessories available to the FJ Cruiser, including such things as running boards, rock rails, roof rack, front skid plate, brush guard, Garmin portable navigation device, spare tire cover, passenger-side armrest, dash applique, tow hitch, cargo mats, and cargo net.
Safety
Side curtain airbags for both rows and side torso airbags optional on 2007 models became standard on 2008 models, Vehicle Stability Control is standard.
The IIHS has awarded the FJ Cruiser its Top Safety Pick accolade. The FJ Cruiser received a "Good" overall rating in both the front and side impacts tests and also received the "Good" rating in all 14 measured categories.
 |
 |
 |
 |
 |
 |
